20%-60%RH Electronic Dry Cabinet

20%-60%RH Electronic Dry Cabinet

  • 20%-60%RH Dry cabinet is especially designed with fully automatic humidity control to prevent moisture related defects. This cabinet is the optimal storage expert for CD/lens/camera/photagraphs. Symor newly developed design greatly increases dehumidifying system which runs faster and more reliable compare to those traditional dry cabinets. it decreases the defective rate at production line meanwhile.all Symor manufactured dry cabinets comply with J-STD-033B standard.



    Related Technical Articles:
    1.Are your MSD safely stored?
    2.Climatest Symor ESD storage moisture proof dry box for MSD storage
    3.What is the application of moisture proof dry cabinet?
    4.What is working principle of electronic dry box?
    5.Electronic Dry Cabinet
    6.What is the specific application of dry cabinet/dry box?
    7.How does dry cabinet work?
    8.Know more about electronic dry cabinet

  • . The whole cabinet adopts 1.2mm galvanized steel with Dupont baking varnish,which is strong corrosion resistant, 3.2mm high intensity toughened glass.reinforced structure,excellent load-bearing and sealing performance.
    . It adopts US import Honeywell humidity sensor; temperature and humidity can be independently displayed,with memory function,no longer to reset humidity after power failure.
    . Symor pass RoHS to claim our cabinets don’t pollute electronics.
    . Zinc alloy lock with perfect air tightness and anti-theft function.
    . Front two ESD casters with brakes for easy move and ESD stand.
    . With Black color (ESD models) or White color(non ESD models).
  • ■ TDA refers to middle humidity series. TDB refers to low humidity series. TDC refers to ultra-low humidity series. TDU refers to bottom humidity series,TDN shows nitrogen cabinet.

    ■ Additional “F”  after ‘A’’B’’C’‘U’’N’ refers to anti-ESD coating type.

    .Data Logger to read humidity curve on PC(Details pls refer to our user manual)

    .Temperature and Humdity display panel(Details pls refer to our specification)

  • File Name : Type: Size: Downloads:
    20-60RH PDF 962.51 KB
