More about UV weathering test chamber
Application: For Mechanical Industrial Products,such as Paint, Coatings, Rubber and Plastic, Printing and Packaging, Stickiness, Motorcycle Industry, Cosmetics, Metal, Electronics, Electroplating, etcCompliance standard: ASTM G 153,ASTM G 154,ASTM D 4329,ASTM D 4799,ASTM D 4587,SAE J 2020,ISO 4892 tests
Feature:
1. UV weather test chamber is made by CNC machine, the shape is beautiful and generous, the chamber cover is two-way flip type, and the operation is simple.
2. imported high-grade # SUS stainless steel plate is used to increase the appearance texture and cleanliness.
3. heating mode is internal tank type heating, fast heating, uniform temperature distribution.
4. drainage system uses vortex type and U type sedimentation device drainage, easy for users to clean.
Technical Parameters:
|
Model |
TA-UV |
|
|
Interiro dimension(mm) |
450×1170×500 |
|
|
Exterior dimension(mm) |
580×1350×1280 |
|
|
Power consumption |
4.0(KW) |
|
|
Performance |
Temperature range |
RT＋10℃～70℃ |
|
RH range |
≥95％R.H |
|
|
Distance btw lamps |
35mm |
|
|
specimen-lamp distance |
50mm |
|
|
Panel quantity |
L300mm×W75mm，appx.20pcs |
|
|
UV wave length |
290nm～400nm UV-A340、UV-B313、UV-C351 |
|
|
Lamp power |
40W |
|
|
Control system |
Temperature controller |
Impored LED Digital display,P.I.D + S.S.R. Microprocessor |
|
Timer |
Programmable PID Microprocessor |
|
| Heating system |
Ni-Cr heater |
|
|
Condensation dehumification system |
|
|
|
Black panel |
Double metal blackboard thermometer |
|
|
Water supply |
Automatic control |
|
|
Exposure mode |
Moisture condensation exposure, light radiation exposure |
|
|
Protection |
Leakage, short circuit, over temperature, water shortage, over current protection |
|
