Ambient requirements of high and low temperature test chamber

The requirements of the temperature test chamber are very strict, There are still many places to take note of, let‘s take a look at it:
a、 Temperature: the ambient temperature of the equipment  requires 5 ℃~ 30 ℃; The manufacturer recommends air conditioning in the end user‘s laboratory to maintain a constant temperature, and prolong the service life of the equipment ,also ensure the accuracy of the experimental results

b、Relative humidity: ≤ 85% ; temperature cycle chamber with excessive humidity around,or there is water spraying machine nearby, may lead to machine rust and other problems

c、Atmospheric pressure: a standard atmospheric pressure (kpa .101.325)

d,  No strong vibration around

e、Without direct sunlight or direct radiation from other heat sources; The ambient temperature should not be too high, Too high will have a certain impact on the equipment compressor including low temperature test.

f、 No strong electromagnetic field around

g、There is no high concentration of dust and corrosive substances around it

The voltage in the workplace must be stable, If the voltage is unstable, Long operation in this environment will cause very obvious damage to the compressor, It is recommended to connect the programmable temperature test chamber with the pressure stabilizer. When installing high and low temperature test chamber, strictly select sites according to the above requirements, so that the thermal test chamber can have a longer service life and a more accurate test.
